IXL Ducted Ventflo Ceiling Fan 250mm

The Ducted Ventflo Ceiling Exhaust Fan is designed to fit a ceiling cavity with a minimum height of 242mm, and has a 150mm diameter duct outlet.

The Ducted Ventflo Fan works by drawing air from the room, and as with all exhaust fans, it is essential that sufficient air inlets exist through windows, vents or under doors.

Ducted Ventflo is compliant with New Zealand G4 Building Codes and Healthy Home Standard for bathrooms and kitchens.

• Impeller housing design provide powerful air flow extraction
• Suitable for bathrooms, kitchens, laundries and toilets
• IP24 rated – can be installed directly above a shower
• Removable fascia for easy cleaning
• Comes with plug for easy installation

1. UPC
   9332048029585
2. Airflow Extraction (m3/h)
   360
3. Aluminium Flexi Ducting
   150 (not included)
4. Back Draught Flaps
   Yes
5. Clearance Required above Unit (mm)
   242
6. Cutout Size (mm)
   295
7. Exhaust Capacity (l/s)
   100
8. Exhaust Capacity (m3/h)
   360
9. Fan Size (mm)
   250
10. IP Rating
    IP24
11. Max. Ceiling Height (m)
    2.4
12. Min. Ceiling Height (m)
    2.1
13. Product Installation
    Can be installed directly above a shower
14. Suitable for Wet/Steamy Area
    Yes
15. Supply (Volts)
    60
16. Area Suitability in Room with Shower
    7.5
