SAL AR111/3500 LED 35W Lamp Module

Application

Design Specifications

• Die-cast aluminium body, black body profile

• High output LED optics, CCT 3000K, 3300lm

• Specially designed optical lens

• High performance changeable multi-faceted reflector system

• Constant current non-dimmable LED driver required, 35w, 1000mA (driver SAL DIM1200/48DC/NR@1000mA)

• Standard beam angles refer Technical Specification table below, AR111/1700: 40° (option), AR111/3500: 20°, 60° (option)

• Lumens: 3300

Performance

• Dimmable - NO
